Size more than Ø 60mm Speaker
Ariose Electronics Co., Ltd. is one of the leading Size more than Ø 60mm Speaker manufacturers in the world. Ariose Electronics Co., Ltd.’s world-class research and development team is focused on developing and commercializing state-of-the-art Speaker. Ariose Electronics Co., Ltd.'s core businesses include the manufacture and distribution of Size more than Ø 60mm Speaker. Also, our products have always been known for quality, reliability and solid performance, making us become the most specified brand in the Size more than Ø 60mm Speaker business.
| 產品型號 Part No. |
直徑 / 尺寸 Diameter /Dimensions |
高度 Height |
形狀 Shape |
額定阻抗 Nominal Impedance |
共振頻率 Resonance Frequency |
頻率響應曲線範圍 Frequency Response |
輸入電壓 (額定/最大) Input Power (Nom./Max.) |
失真 Distortion |
音壓 Sound Pressure Level |
| (mm) | (mm) | (Ω) | (Hz) | (KHz) | |||||
| LF-K6666B22A | 66.0*66.0 | 22.5 | 方形 Square |
8.0 ± 15% | 500 ± 20% | Fo ～20.0 | 4.0W / 5.0W | Max. 5% at 1KHz input 4.0W |
99 ± 3dB average 300Hz~3,000Hz Input 2.83Vrms sine wave at 50cm |
| LF-K66B200B | ø66.0 | 20.0 | 圓形 Round |
8.0 ± 15% | 420 ± 20% | 0.4 ~ 4.0 | 0.5W / 1.0W | Max. 5% at 800Hz input 0.5W |
86 ± 3dB average 300Hz~4,000Hz Input 2.0Vrms sine wave at 50cm |
| LF-K70B17A | ø670.0 | 14.0 | 圓形 Round |
8.0 ± 15% | 280 ± 100 | Fo ～4.0 | 3.0W / 4.0W | Max. 5% at 1KHz input 3.0W |
89 ± 3dB average 300Hz~3,000Hz Input 2.83Vrms sine wave at 50cm |
| LF-K77B21A | ø77.0 | 22.5 | 圓形 Round |
8.0 ± 15% | 380 ± 20% | Fo ～17.0 | 5.0W / 7.0W | Max. 5% at 1KHz input 5.0W |
92 ± 3dB average 300Hz~2,000Hz Input 2.83Vrms sine wave at 50cm |
| LF-K77B28B | 77.0*77.0 | 28.5 | 方形 Square |
8.0 ± 15% | 300 ± 20% | Fo ～3.2 | 2.0W / 3.0W | Max. 5% at 800Hz input 2.0W |
93 ± 3dB average 200Hz~2,000Hz Input 2.83Vrms sine wave at 50cm |
| LF-K8080A405A-WPF | 80.0*80.0 | 43.0 | 方形 Square |
4.0 ± 20% at 2KHz |
111 ± 20% | Fo ～20.0 | 8.0W / 10.0W | Max. 5% at 1KHz input 8.0W |
87 ± 3dB average 500Hz~2,000Hz Input 5.65Vrms sine wave at 100cm |
| LF-K8080A415A-WPF | 80.0*80.0 | 43.0 | 方形 Square |
4.0 ± 20% at 2KHz |
113 ± 20% | Fo ～20.0 | 10.0W / 12.0W | Max. 5% at 1KHz input 10.0W |
87 ± 3dB average 500Hz~3,000Hz Input 6.32Vrms sine wave at 100cm |
LF-K102102B375C | 102.0*102.0 | 37.5 | 方形 Square |
8.0 ± 15% | 120 ± 20% | Fo ~ 12.0 | 7.5W / 10W | Max. 5% at 1KHz input 7.5W |
83 ± 3dB average 120Hz~2,000Hz Input 2.83Vrms sine wave at 100cm |
Ariose Electronics Co., Ltd. has a team of knowledgeable people and a wide range of great quality performance Size more than Ø 60mm Speaker products. As a quality centric organization, we follow international quality standards throughout our business process. We offer our services using advance technology and good quality raw materials in adherence with the set international quality standards. Our Size more than Ø 60mm Speaker is highly appreciated among our clients for their optimum and superior quality. If you have any questions, want to buy in bulk, or have us give you a quote for Size more than Ø 60mm Speaker to fit your needs, please email to us.
