Piezoelectric Buzzer (External Drive)
Ariose Electronics Co., Ltd. is committed to developing Piezoelectric Buzzer (External Drive) that ultimately create innovative products that exceed customer expectations. We are the global leader in electronic supplies. We develop, manufacture and distribute groundbreaking Buzzer that shatter the status quo and help customers gain and maintain a competitive edge. We believe that our Piezoelectric Buzzer (External Drive) have very great potential for this type of development in electronic supplies industry. Ariose Electronics Co., Ltd. is committed to developing Piezoelectric Buzzer (External Drive) that ultimately create innovative products that exceed customer expectations.
產品型號 Part No. |
直徑 / 尺寸 Diameter / Dimensions |
高度 Height |
形狀 Shape |
款式 Type |
最大工作電壓 Max. Operating Voltage |
靜電容量 Capacitance |
共振頻率 Resonance Frequency |
音壓 Sound Pressure Level |
(mm) | (mm) | (VP-P) | (At 120Hz) | (Hz) | ||||
LF-PE10W32A | Φ10.0 | 3.2 | 圓形 Round |
線 Wire | Max. 30 | 11,000pF ± 30% | 3,200 | Min. 75 dB 9 VP-P / 3,200Hz square wave / 10 cm |
LF-PE12T40B | 12.0*12.0 | 3.0 | 方形 Square |
SMT | Max. 25 | 16,000pF ± 30% | 4,000 | Min. 77 dB 5 VP-P / 4,000Hz square wave / 10 cm |
LF-PE13P40H | Φ12.8 | 6.2 | 圓形 Round |
DIP | Max. 25 | 12,000pF ± 30% | 4,000 | Min. 89 dB 9 VP-P / 4,000Hz square wave / 10 cm |
LF-PE13T40A | Φ13.0 | 7.0 | 圓形 Round |
DIP | Max. 30.0 | 17,000pF ± 30% | 4,000 | Min. 88 dB 9 VP-P / 4,000Hz square wave / 10 cm |
LF-PE14P40A-50 | Φ14.0 | 6.0 | 圓形 Round |
DIP | Max. 20 | 18,000pF ± 30% | 4,096 | Min. 88 dB 9 VP-P / 4,096Hz square wave / 10 cm |
LF-PE14P40A-75 | Φ14.0 | 6.0 | 圓形 Round |
DIP | Max. 20 | 18,000pF ± 30% | 4,096 | Min. 88 dB 9 VP-P / 4,096Hz square wave / 10 cm |
LF-PE14P40E-A | Φ13.8 | 6.8 | 圓形 Round |
DIP | Max. 30 | 10,000pF ± 30% | 4,000 | Min. 85 dB 9 VP-P / 4,000Hz square wave / 10 cm |
LF-PE14T40B | Φ14.0 | 6.5 | 圓形 Round |
SMT | Max. 15 | 15,000pF ± 30% | 4,000 | Min. 85 dB 9 VP-P / 4,000Hz square wave / 10 cm |
LF-PE14W40A | Φ14.0 | 4.0 | 圓形 Round |
線 Wire | Max. 20 | 15,000pF ± 30% | 4,800 | Min. 85 dB 9 VP-P / 4,800Hz square wave / 10 cm |
LF-PE17W40A-85 | Φ16.5 | 4.0 | 圓形 Round |
線 Wire | Max. 20 | 14,000pF ± 30% | 4,000 | Min. 88 dB 9 VP-P / 4,000Hz square wave / 10 cm |
LF-PE22P40A-10C | Φ22.0 | 7.0 | 圓形 Round |
DIP | Max. 30 | 15,000pF ± 30% | 4,000 | Min. 92 dB 9 VP-P / 4,000Hz square wave / 10 cm |
LF-PE22P40A-10D | Φ22.0 | 7.0 | 圓形 Round |
DIP | Max. 30 | 15,000pF ± 30% | 4,000 | Min. 92 dB 9 VP-P / 4,000Hz square wave / 10 cm |
LF-PE22P40C-10C | Φ22.0 | 10.6 | 圓形 Round |
DIP | Max. 30 | 15,000pF ± 30% | 4,000 | Min. 98 dB 9 VP-P / 4,000Hz square wave / 10 cm |
LF-PE22P40C-10D | Φ22.0 | 10.6 | 圓形 Round |
DIP | Max. 30 | 15,000pF ± 30% | 4,000 | Min. 98 dB 9 VP-P / 4,000Hz square wave / 10 cm |
LF-PE23S20B | 22.0*26.5 | 7.0 | 馬蹄形 horseshoe |
DIP | Max. 20 | 25,000pF ± 30% | 2,000 | Min. 88 dB 9 VP-P / 2,000Hz square wave / 10 cm |
LF-PE24P40A | Φ24.0 | 5.5 | 圓形 Round |
DIP | Max. 30 | 25,000pF ± 30% | 4,000 | Min. 94 dB 9 VP-P / 4,000Hz square wave / 10 cm |
LF-PE24W40A | Φ24.0 | 5.5 | 圓形 Round |
線 Wire | Max. 30 | 25,000pF ± 30% | 4,000 | Min. 90 dB 9 VP-P / 4,000Hz square wave / 10 cm |
LF-PE24W60A | Φ24.0 | 5.5 | 圓形 Round |
線 Wire | Max. 40 | 15,000pF ± 30% | 6,000 | Min. 94 dB 9 VP-P / 6,000Hz square wave / 10 cm |
LF-PE24W60B | Φ24.0 | 5.5 | 圓形 Round |
線 Wire | Max. 40 | 13,000pF ± 30% | 6,000 | Min. 94 dB 9 VP-P / 6,000Hz square wave / 10 cm |
LF-PE30P38A | Φ30.0 | 8.2 | 圓形 Round |
DIP | Max. 30 | 20,000pF ± 30% | 3,800 | Min. 92 dB 9 VP-P / 3,800Hz square wave / 10 cm |
LF-PE30W40A | Φ29.5 | 5.5 | 圓形 Round |
線 Wire | Max. 30 | 28,000pF ± 30% | 4,000 | Min. 96 dB 9 VP-P / 4,000Hz square wave / 10 cm |
LF-PE35W11A-B | Φ34.5 | 9.0 | 圓形 Round |
DIP | Max. 40 | 50,000pF ± 30% | 1,100 | Min. 85 dB 9 VP-P / 1,100Hz square wave / 10 cm |
LF-PE42W29A | Φ41.7 | 16.0 | 圓形 Round |
線 Wire | Max. 30 | 30,000pF ± 30% | 2,900 | Min. 100 dB 9 VP-P / 2,900Hz square wave / 10 cm |
LF-PE44W10B-B | Φ44.0 | 14.0 | 圓形 Round |
線 Wire | Max. 30 | 65,000pF ± 30% | 1,000 | Min. 92 dB 9 VP-P / 1,000Hz square wave / 10 cm |
LF-PE50W10A-B | Φ50.0 | 2.0 | 圓形 Round |
線 Wire | Max. 40 | 90,000pF ± 30% | 750 | Min. 78 dB 9 VP-P / 750Hz square wave / 10 cm |
Ariose Electronics Co., Ltd., the world’s leading manufacturer of Piezoelectric Buzzer (External Drive), is positioned at the leading edge of innovation and service, providing the most comprehensive Piezoelectric Buzzer (External Drive) solutions packages to its customers via a portfolio of highly recognized brands. We are a global manufacturer of high quality Piezoelectric Buzzer (External Drive) and our company's internal strategy to continually improve quality and delivery meant the Piezoelectric Buzzer (External Drive) was a product fit for the customers. If you are looking for Piezoelectric Buzzer (External Drive) manufacturing company, let us be your answer.
